Solar Water Heater (Global Renewable Energy)
Solar Water Heater
Price available on order
Technical Specifications
Inner cylinder
Made of food grade chrome AB 304 SS, stainless and magnet adhesion, surrounded by a layer of high-density insulating foam (two crystals 40 kg 3 m), thickness MM50.
The outer cylinder
Available in two types that are resistant to rust and weathering - 1 polychrome - 2 stainless steel
Cold water inlet
1/2 inch copper ball and the hot water outlet is a 3/4 inch copper ball
Welding method
Argon welding of metal type
Internal gaskets
UV treatment
Operating pressure
Unpressurized system check pressure 2 bar
Glass tubes
Three layers of hollow copper borosilicate with an absorption coefficient of 94%, with a maximum temperature of up to 200 degrees Celsius and a lifespan of 15-20 years.
Total tank capacity
30 tubes equal 330 litres
Total tank capacity
24 tubes equal approximately 270 litres.
Total tank capacity
20 tubes equal approximately 230 litres.
Al-Qaeda
Forged iron at an angle of approximately 45 degrees.
Base dimensions
170-155-242cm
